a. Double-click in the Assignment Name column and scroll to the bottom of the available
assignments.
b. Select VCCR_GXB/VCCT_GXB Voltage.
c. In the Value column, select 1_0V from the list.
The Quartus II software adds these instance assignments commands to the .qsf file for your project.
Analog Settings for Arria V Devices
Analog Settings for Arria V Devices
This section lists the analog parameters for Arria V devices whose original values are place holders for the
values that match your electrical board specification. In the following table, the default value of an analog
parameter is shown in bold type. The parameters are listed in alphabetical order.
The following table lists the analog parameters with global or computed default values. You may want to
optimize some of these settings. The default value is shown in bold type. For computed analog
parameters, the default value listed is for the initial setting, not the recomputed setting. The parameters
are listed in alphabetical order.
For more information about the Pin Planner, refer to About the Pin Planner in Quartus II Help. For more
information about the Assignment Editor, refer to About the Assignment Editor in Quartus II Help.
For more information about Quartus II Settings, refer to Quartus II Settings File Manual.
Related Information
•
•
•
•
XCVR_IO_PIN_TERMINATION
Pin Planner and Assignment Editor Name
Transceiver I/O Pin Termination
Description
Specifies the intended on-chip termination value for the specified transceiver pin. Use External Resistor if
you intend to use off-chip termination.
Options
• 85_Ohms
• 100_Ohms
• 120_Ohms
• 150_Ohms
• External_Resistor
19-2
Analog Settings for Arria V Devices
UG-01080
2015.01.19
Altera Corporation
Analog Parameters Set Using QSF Assignments
