When you specify multiple .spd files, the
ip-make-simscript
utility generates a single simulation script
containing all required simulation information. The default value of
TOP_LEVEL_NAME
is the
TOP_LEVEL_NAME
defined in the IP core or Qsys .spd file. If this is not the top-level instance in your
design, specify the top-level instance of your testbench or design.
You can set appropriate variables in the script or edit the variable assignments directly in the script. If the
simulation script is a Tcl file that can be sourced in the simulator, set the variables before sourcing the
script. If the simulation script is a shell script, pass in the variables as command-line arguments to shell
script.
To run
ip-make-simscript
, type the following at the command prompt:
\quartus\sopc_builder\bin\ip-make-simscript
The following tables lists some of the options available with this utility.
Table 1-3: Options for the
ip-make-simscript
Utility
Option Description Status
--spd= Describes the list of compiled files and
memory model hierarchy. If your design
includes multiple IP cores or Qsys systems
that include .spd files, use this option for each
file. For example:
ip-make-simscript --spd=ip1.spd --
spd=ip2.spd
Require
d
--output-
directory=
Directory path specifying the location of
output files. If unspecified, the default setting
is the directory from which
ip-make-
simscript
is run.
Option
al
--compile-to-work Compiles all design files to the default work
library. Use this option only if you encounter
problems managing your simulation with
multiple libraries.
Option
al
--use-relative-paths
Uses relative paths whenever possible Option
al
To learn about all options for the
ip-make-simscript
, type the following at the command prompt:
\quartus\sopc_builder\bin\ip-make-simscript --help
Related Information
• Mentor Graphics ModelSim Support
• Simulating Altera Designs
Unsupported Features
The protocol-specific and native transceiver PHYs are not supported in Qsys in the current release.
