Phy analog parameters, Phy analog parameters -6 – Altera Transceiver PHY IP Core User Manual
Page 115
Parameter Name
Options
Description
Link fail inhibit time for 10Gb
Ethernet
504 ms
Specifies the time before
link_status
is set to
FAIL or OK. A link fails if the
link_fail_
inhibit_time
has expired before
link_status
is set to OK. The legal range is 500-510 ms. For
more information, refer to "Clause 73 Auto
Negotiation for Backplane Ethernet" in IEEE Std
802.3ap-2007.
Link fail inhibit time for 1Gb
Ethernet
40-50 ms
Specifies the time before
link_status
is set to
FAIL or OK . A link fails if the link_fail_inhibit_
time has expired before
link_status
is set to
OK. The legal range is 40-50 ms.
PHY Analog Parameters
You can specify analog parameters using the Quartus II Assignment Editor, the Pin Planner, or the
Quartus II Settings File (.qsf).
Related Information
•
Analog Settings for Arria V GZ Devices
on page 19-11
•
Analog PCB Settings for Stratix V Devices
on page 19-34
5-6
PHY Analog Parameters
UG-01080
2015.01.19
Altera Corporation
1G/10 Gbps Ethernet PHY IP Core
