ATM Controller and AAL0, AAL1, and AAL5
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
Freescale Semiconductor 30-43
Table 30-16 describes RCT fields.
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Offset + 0x00 — GBL BO — DTB BIB — BUFM SEGF ENDF — INTQ
Offset + 0x02 — INF — ABRF AAL
Offset + 0x04 RX Data Buffer Pointer (RXDBPTR)
Offset + 0x06
Offset + 0x08 Cell Time Stamp
Offset + 0x0A
Offset + 0x0C RBD_Offset
Offset + 0x0E Protocol Specific
• For AAL5, Section 30.10.2.2.1, “AAL5 Protocol-Specific RCT .”
• For AAL2, Section 32.4.4.1, “AAL2 Protocol-Specific RCT .”
• For AAL1, Section 30.10.2.2.3, “AAL1 Protocol-Specific RCT .”
• For AAL1 CES, Section 31.9.1.1, “AAL1 CES Protocol-Specific RCT ”
• For AAL0, Section 30.10.2.2.4, “AAL0 Protocol-Specific RCT .”
Offset + 0x10
Offset + 0x12
Offset + 0x14
Offset + 0x16
Offset + 0x18
Offset + 0x1A MRBLR
Offset + 0x1C — PMT RBD_BASE
Offset + 0x1E RBD_BASE — PM
Figure 30-25. Receive Connection Table (RCT) Entry
