CPM Multiplexing
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
Freescale Semiconductor 16-7
NOTE
After a clock source is selected, the clock is given an internal name. For the
FCCs and SCCs, the names are RCLKx and TCLKx; for SMCs, the name is
simply SMCLKx. These internal names are used only in NMSI mode to
specify the clocks sent to the FCCs, SCCs or SMCs. These names do not
correspond to any PowerQUICC II pins.
16.4 CMX Registers
The following sections describe the CMX registers.
16.4.1 CMX UTOPIA Address Register (CMXUAR)
NOTE
This section does not apply to the MPC8250.
The CMX UTOPIA address register (CMXUAR), shown in Figure 16-4 , defines the connection of FCC1
and FCC2 UTOPIA multiple-PHY addresses to the twenty UTOPIA address pins of the PowerQUICC II;
it also defines the connection of a BRG to the FCCs when an internal rate feature is used. This enables the
user to implement a multiple-PHY UTOPIA master or slave on both FCC1 and FCC2 using only twenty
pins. The user chooses how many PHYs to use with each interface and how many address lines are needed
for each FCC.
Table 16-2 describes CMXUAR fields.
0 1 2 3 4 5 6 7 8 9 10 11 12 15
Field SAD0 SAD1 SAD2 SAD3 SAD4 — MAD4 MAD3 F1IRB F2IRB —
Reset 0000_0000_0000_0000
R/W R/W
Addr 0x0x11B0E
Figure 16-4. CMX UTOPIA Address Register (CMXUAR)
Table 16-2. CMXUAR Field Descriptions
Bits Name Description
0–4 SAD x Slave address input pin x connection. Note that the address indexes are relative to FCC1; see
Figure 16-7 .
0 This address input pin is used by FCC2 in slave mode.
1 This address input pin is used by FCC1 in slave mode.
5 — Reserved, should be cleared.
6–7 MAD x Master address output pin x connection. Note that the address indexes are relative to FCC1; see
Figure 16-7 .
0 This address output pin is used by FCC2 in master mode.
1 This address output pin is used by FCC1 in master mode.
