Communications Processor Module Overview
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
Freescale Semiconductor 14-21
Table 14-10. Parameter RAM
Page Address
1
1
Offset from RAM_BASE
Peripheral
Size
(Bytes)
1 0x8000 SCC1 256
2 0x8100 SCC2 256
3 0x8200 SCC3 256
4 0x8300 SCC4 256
5 0x8400 FCC1 256
6 0x8500 FCC2 256
7 0x8600 FCC3
2
2
Reserved on the MPC8255.
256
8 0x8700 MCC1
3
3 Reserved on the MPC8250 and the MPC8255.
128
0x8780 Reserved 124
0x87FC SMC1_BASE 2
0x87FE IDMA1_BASE 2
9 0x8800 MCC2 128
0x8880 Reserved 124
0x88FC SMC2_BASE 2
0x88FE IDMA2_BASE 2
10 0x8900 Reserved 252
0x89FC SPI_BASE 2
0x89FE IDMA3_BASE 2
11 0x8A00 Reserved 224
0x8AE0 RISC Timers 16
0x8AF0 REV_NUM
4
4
Refer to Table 14-5 .
2
0x8AF2 Reserved 2
0x8AF4 Reserved 4
0x8AF8 RAND 4
0x8AFC I
2
C_BASE 2
0x8AFE IDMA4_BASE 2
12-16 0x8B00 Reserved 1280
