Parallel I/O Ports
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
40-10 Freescale Semiconductor
PA17 FCC1: RxD[7]
1
UTOPIA 8
FCC1: RxD[15]
1
UTOPIA 16
FCC1: RxD[0]
MII/HDLC nibble
FCC1: RxD
HDLC/transp.
GND
PA16 FCC1: RxD[6] 1
UTOPIA 8
FCC1: RxD[14] 1
UTOPIA 16
FCC1: RxD[1]
MII/HDLC nibble
GND
PA15 FCC1: RxD[5]
1
UTOPIA 8
FCC1: RxD[13]
1
UTOPIA 16
FCC1: RxD[2]
MII/HDLC nibble
GND
PA14 FCC1: RxD[4]
1
UTOPIA 8
FCC1: RxD[12]
1
UTOPIA 16
FCC1: RxD[3]
MII/HDLC nibble
GND
PA13 FCC1: RxD[3] 1
UTOPIA 8
FCC1: RxD[11]
1
UTOPIA 16
GND MSNUM[2] 2
PA12 FCC1: RxD[2]
1
UTOPIA 8
FCC1: RxD[10]
1
UTOPIA 16
GND MSNUM[3]
2
PA11 FCC1: RxD[1] 1
UTOPIA 8
FCC1: RxD[9]
1
UTOPIA 16
GND MSNUM[4] 2
PA10 FCC1: RxD[0]
1
UTOPIA 8
FCC1: RxD[8]
1
UTOPIA 16
GND MSNUM[5]
2
Table 40-5. Port A—Dedicated Pin Assignment (PPARA = 1) (continued)
Pin
Pin Function
PSORA = 0 PSORA = 1
PDIRA = 1 (Output) PDIRA = 0 (Input)
Defaul
t Input
PDIRA = 1 (Output)
PDIRA = 0 (Input, or
Inout if Specified)
Defaul
t Input
