Serial Interface with Time-Slot Assigner
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
15-34 Freescale Semiconductor
NOTE
If SCIT mode is not used, delete the last three entries of the SIx RAM, divide
one entry into two and set the LST bit in the new last entry.
3. CMXSMR = 0x88. SMC1 and SMC2 are connected to the TSA.
4. CMXSCR = 0xC040_0000. SCC2 and SCC1 are connected to the TSA. SCC1 supports the grant
mechanism since it is on the D channel.
5. CMXSI1CR = 0x00. TDMa uses CLK1.
6. Set PPARA[6–9]. Configures L1TXDa[0], L1RXDa[0], L1TSYNCa and L1RSYNCa.
7. Set PSORA[6–9]. Configures L1TXDa[0], L1RXDa[0], L1TSYNCa and L1RSYNCa.
8. Set PDIRA[9]. Configures L1TXDa[0].
9. Set PODRA[9]. Configures L1TXDa[0] to an open-drain output.
10. Set PPARC[30,31]. Configures L1TCLKa and L1RCLKa.
11. Clear PDIRC[30,31]. Configures L1TCLKa and L1RCLKa.
12. Clear PSORC[30,31]. Configures L1TCLKa and L1RCLKa.
13. Set PPARB[17]. Configures L1CLKO and L1RQa.
14. Clear PSORB[17]. Configures L1CLKO and L1RQa.
15. Set PDIRB[17]. Configures L1CLKO and L1RQa.
16. If the 1x GCI data clock is required, set PBPAR bit 16 and PBDIR bit 16 and clear PSORB 16,
which configures L1CLKOa as an output.
17. Configure SCC1 for HDLC operation (to handle the LAPD protocol of the D channel). Configure
SMC1 for SCIT operation and configure SCC2 and SMC2 as preferred.
18. SI1GMR = 0x11. Enable TDMa (one static TDM), STZ for TDMa.
19. SI1CMDR is not used.
20. SI1STR does not need to be read.
21. Enable the SCC1, SCC2, SMC1 and SMC2.
