System Interface Unit (SIU)
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
4-26 Freescale Semiconductor
Table 4-8 describes SIEXR fields.
4.3.2 System Configuration and Protection Registers
The system configuration and protection registers are described in the following sections.
4.3.2.1 Bus Configuration Register (BCR)
The bus configuration register (BCR), shown in Figure 4-21 , contains configuration bits for various
features and wait states on the 60x bus.
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Field EDPC0 EDPC1 EDPC2 EDPC3 EDPC4 EDPC5 EDPC6 EDPC7 EDPC8 EDPC9 EDPC
10
EDPC
11
EDPC
12
EDPC
13
EDPC
14
EDPC
15
Reset 0000_0000_0000_0000
R/W R/W
Addr 0x0x10C24
16 17 18 19 20 21 22 23 24 31
Field EDI0 EDI1 EDI2 EDI3 EDI4 EDI5 EDI6 EDI7 —
Reset 0000_0000_0000_0000
R/W R/W R
Addr 0x10C26
Figure 4-20. SIU External Interrupt Control Register (SIEXR)
Table 4-8. SIEXR Field Descriptions
Bits Name Description
0–15 EDPCx Edge detect mode for port Cx. The corresponding port C line (PCx) asserts an interrupt request
according to the following:
0 Any change on PCx generates an interrupt request.
1 High-to-low change on PCx generates an interrupt request.
16–23 EDIx Edge detect mode for IRQ x . The corresponding IRQ line (IRQx) asserts an interrupt request
according to the following:
0 Low assertion on IRQ
x generates an interrupt request.
1 High-to-low change on IRQ x generates an interrupt request.
