System Interface Unit (SIU)
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
Freescale Semiconductor 4-15
6 IDMA1 0b00_0110
7 IDMA2 0b00_0111
8 IDMA3 0b00_1000
9 IDMA4 0b00_1001
10 SDMA 0b00_1010
11 Reserved 0b00_1011
12 Timer1 0b00_1100
13 Timer2 0b00_1101
14 Timer3 0b00_1110
15 Timer4 0b00_1111
16 TMCNT 0b01_0000
17 PIT 0b01_0001
18 PCI
1
0b01_0010
19 IRQ1 0b01_0011
20 IRQ2 0b01_0100
21 IRQ3 0b01_0101
22 IRQ4 0b01_0110
23 IRQ5 0b01_0111
24 IRQ6 0b01_1000
25 IRQ7 0b01_1001
26–31 Reserved 0b01_1010–01_1111
32 FCC1 0b10_0000
33 FCC2 0b10_0001
34 FCC3 0b10_0010
35 Reserved 0b10_0011
36 MCC1
2
0b10_0100
37 MCC2 0b10_0101
38 Reserved 0b10_0110
39 Reserved 0b10_0111
40 SCC1 0b10_1000
41 SCC2 0b10_1001
42 SCC3 0b10_1010
43 SCC4 0b10_1011
Table 4-3. Encoding the Interrupt Vector (continued)
Interrupt Number Interrupt Source Description Interrupt Vector
