ATM Controller and AAL0, AAL1, and AAL5
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
30-38 Freescale Semiconductor
0x78 VPT1_BASE /
EXT_CAM1_BASE
Word Base address of the address compression VP1 table/EXT CAM1.
User-defined.
0x7C VCT1_BASE Word Base address of the address compression VC1 table. User-defined.
0x80 VP_MASK Hword VP mask for address compression lookup. User-defined.
0x82 VCIF Hword VCI filtering enable bits. When cells with VCI = 3, 4, 6, 7-15 are received
and the associated VCIF bit = 1 the cell is sent to the raw cell queue.
VCIF[0–2, 5] should be zero. See
Section 30.10.1.2, “VCI Filtering
(VCIF) .”
0x84 GMODE Hword Global mode. User-defined. See Section 30.10.1.3, “Global Mode Entry
(GMODE) .”
0x86 COMM_INFO Hword The information field associated with the last host command.
User-defined. See Section 30.14, “ATM Transmit Command .”
0x88 Hword
0x8A Hword
0x8C — Word Reserved, should be cleared.
0x90 CRC32_PRES Word Preset for CRC32. Initialize to 0xFFFF_FFFF.
0x94 CRC32_MASK Word Constant mask for CRC32. Initialize to 0xDEBB_20E3.
0x98 AAL1_SNPT_BASE Hword AAL1 SNP protection look-up table base address. (AAL1 CES only.) The
32-byte table resides in dual-port RAM. AAL1_SNPT_BASE must be
halfword-aligned. User-defined offset from dual-port RAM base. See
Section 30.10.6, “AAL1 Sequence Number (SN) Protection Table .”
0x9A — Hword Reserved, should be cleared.
0x9C SRTS_BASE Word External SRTS logic base address. AAL1 CES only. Should be 16-byte
aligned. The four least-significant bits are taken from SRTS_DEV in the
AAL1-specific area of the connection table entries.
0xA0 IDLE/UNASSIGN_BAS
E
Hword Idle/unassign cell base address. Points to dual-port RAM area contains
idle/unassign cell template (little-endian format). Should be 64-byte
aligned. User-defined offset from dual-port RAM base. The ATM header
should be 0x0000_0000 or 0x0100_0000 (CLP=1).
0xA2 IDLE/UNASSIGN_SIZE Hword Idle/unassign cell size. 52 in regular mode; 53–64 in UDC mode.
0xA4 EPAYLOAD Word Reserved payload. Initialize to 0x6A6A_6A6A.
0xA8 Trm Word (ABR only) The upper bound on the time between F-RM cells for an active
source. TM 4.0 defines the Trm period as 100 msec. The Trm value is
defined by the system clock and the time stamp timer prescaler; see
Section 14.3.8, “RISC Time-Stamp Control Register (RTSCR) .” For time
stamp prescalar of 1µs, program Trm to be 100 ms/1µs = 100,000.
0xAC Nrm Hword (ABR only) Controls the maximum cells the source may send for each
F-RM cell. Set to 32 cells.
0xAE Mrm Hword (ABR only) Controls the bandwidth between F-RM, B-RM and user data
cell. Set to 2 cells.
Table 30-11. ATM Parameter RAM Map (continued)
Offset
1
Name Width Description
