Memory Map
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
3-12 Freescale Semiconductor
0x1133C FCC2 transmit internal rate registers for PHY0
(FTIRR2_PHY0)
R/W 8 bits 0x00 30.13.4/30-91
(ATM)
33.4.2.1.2/33-26
(IMA)
0x1133D FCC2 transmit internal rate registers for PHY1
(FTIRR2_PHY1) R/W 8 bits 0x00
0x11133E FCC2 transmit internal rate registers for PHY2
(FTIRR2_PHY2)
R/W 8 bits 0x00
0x1133F FCC2 transmit internal rate registers for PHY3
(FTIRR2_PHY3) R/W 8 bits 0x00
FCC3 3
0x11340 FCC3 general mode register (GFMR3) 3 R/W 32 bits 0x0000_0000 29.2/29-3
0x11344 FCC3 protocol-specific mode register (FPSMR3) 3 R/W 32 bits 0x0000_0000 30.13.2/30-88
(ATM)
33.4.2.1.1/33-26
(IMA)
35.18.1/35-18
(Ethernet)
36.6/36-7
(HDLC)
0x11348 FCC3 transmit on-demand register (FTODR3)
3
R/W 16 bits 0x0000 29.5/29-8
0x1134A Reserved — 16 bits — —
0x1134C FCC3 data synchronization register (FDSR3)
3
R/W 16 bits 0x7E7E 29.4/29-8
0x1134E Reserved — 16 bits — —
0x11350 FCC3 event register (FCCE3)
3
R/W 16 bits 0x0000_0000 30.13.3/30-90
(ATM)
35.18.2/35-20
(Ethernet)
36.9/36-14
(HDLC)
0x11352 Reserved — 16 bits — —
0x11354 FCC3 mask register (FCCM3)
3
R/W 16 bits 0x0000_0000 30.13.3/30-90
(ATM)
35.18.2/35-20
(Ethernet)
36.9/36-14
(HDLC)
0x11356 Reserved — 16 bits — —
0x11358 FCC3 status register (FCCS3)
3
R 16 bits 0x00 36.10/36-16
(HDLC)
0x11359–
0x113FF
Reserved — 167
bytes
— —
Table 3-1. Internal Memory Map (continued)
Address
(offset)
Register R/W Size Reset Section/Page
