Memory Controller
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
Freescale Semiconductor 11-51
Now, from the SDRAM device point of view, during an ACTIVATE command, its address port should look
like Table 11-27 .
Table 11-20. indicates that in order to multiplex A[6–19] over A[15–28] PSDMR[SDAM] must be 001
and, because the internal bank selects are multiplexed over A[15–16] PSDMR[BSMA] must be 010 (only
the lower two bank select lines are used).
During a READ / WRITE command, the address port should look like Table 11-28 .
Because AP alternates with A[9] of the row lines, set PSDMR[SDA10] = 011. This outputs A[9] on the
SDA10 line during the ACTIVATE command and AP during READ/WRITE and CBR commands.
Table 11-29. shows the register configuration. Not shown are PSRT and MPTPR, which should be
programmed according to the device refresh requirements.
11.5 General-Purpose Chip-Select Machine (GPCM)
Users familiar with the MPC8xx memory controller should read Section 11.5.4, “Differences between
MPC8xx’s GPCM and MPC82xx’s GPCM,” first.
Table 11-27. SDRAM Device Address Port during ACTIVATE Command
“A[0–14]” A[15–16] A[17–28] A[29–31]
— Internal bank select (A[6–7]) Row (A[8–19]) n.c.
Table 11-28. SDRAM Device Address Port during READ / WRITE Command
“A[0–14]” A[15–16] A[17] A[18] A[19] A[20–28] A[29–31]
— Internal bank select Don’t care AP Don’t care Column n.c.
Table 11-29. Register Settings (Bank-Based Interleaving)
Register Settings
BR x BA Base address
PS00 = 64-bit port size
DECC00
WP0
MS010 = SDRAM-60x bus EMEMC0
ATOM00
DR0
V 1
OR x SDAM1111_1100_0000
LSDAM00000
BPD01
ROWST010 NUMR011
PMSEL0
IBID0
PSDMR PBI0
RFEN1
OP000
SDAM001
BSMA010
SDA10011
RFRC from device data sheet
PRETOACT from device data sheet ACTTOROWfrom device data sheet
BL 0
LDOTOPREfrom device data sheet
WRC from device data sheet
EAMUX0
BUFCMD0
CL from device data sheet
