System Interface Unit (SIU)
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
4-42
Freescale Semiconductor
4.3.2.12
Local Bus Transfer Error Status and Control Register 1 (L_TESCR1)
The local bus transfer error status and control register 1 (L_TESCR1) is shown in
The L_TESCR1 register bits are described in
0
1
2
3
4
5
6
7
9
10
11
15
Field
BM
—
PAR
—
WP
—
TC
—
TT
Reset
0000_0000_0000_0000
R/W
R/W
Addr
16
17
18
19
20
21
31
Field
—
DMD
—
DER
1
—
Reset
0000_0000_0000_0000
R/W
R/W
Addr
0x1004A
1
.29
µm (HiP3) Rev B.3 silicon and forward. Reserved on .29µm Rev A.1 devices.
Note: Bits 0–15 and 19–23 are status bits and are cleared by writing 1s.
Figure 4-33. Local Bus Transfer Error Status and Control Register 1 (L_TESCR1)
Table 4-17. L_TESCR1 Field Descriptions
Bits
Name
Description
0
BM
Bus monitor time-out. Indicates that TEA was asserted due to the local bus monitor time-out.
1
—
Reserved, should be cleared.
2
PAR
Parity error. Indicates that MCP was asserted due to parity error on the local bus. L_TESCR2[PB]
indicates the byte lane that caused the error and L_TESCR2[BNK] indicates which memory
controller bank was accessed.
3–4
—
Reserved, should be cleared.
5
WP
Write protect error. Indicates that a write was attempted to a local bus memory region that was
defined as read-only in the memory controller. Note that this alone does not cause TEA assertion.
Usually, in this case, the bus monitor will time-out.
6
—
Reserved, should be cleared.
7–9
TC
Transfer code. Indicates the transfer code of the local bus transaction that caused the TEA.
000 60x-local bridge
001 Reserved
010 Local DMA function code 0
011 Local DMA function code 1
1xx Reserved
10
—
Reserved, should be cleared.
11–15
TT
Transfer type. Indicates the transfer type of the local bus transaction that caused the TEA.
Section 8.4.3.1, “Transfer Type Signal (TT[0–4]) Encoding,”
describes the various transfer types.
16
—
Reserved, should be cleared.
