ATM AAL1 Circuit Emulation Service
MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
Freescale Semiconductor 31-23
0x44 UDC_TMP_BASE Hword UDC mode only. Points to a total of 32 bytes reserved dual-port RAM
area used by the CP. Should be 64-byte aligned. User-defined.
(recommended address space: 3000h-4000h or b000h-c000h)
0x46 INT_RCT_BASE Hword Internal receive connection table base. User-defined.
0x48 INT_TCT_BASE Hword Internal transmit connection table base. User-defined.
0x4A INT_TCTE_BASE Hword Internal transmit connection table extension base. User-defined. Note
that the TCT extension is not needed in AAL1 CES and that the AAL1
CES microcode uses this Hword to point to a CAS routing table.
0x4C — Word Reserved, should be cleared during initialization.
0x50 EXT_RCT_BASE Word External receive connection table base. User-defined.
0x54 EXT_TCT_BASE Word External transmit connection table base. User-defined.
0x58 EXT_TCTE_BASE Word External transmit connection table extension base. User-defined. Note
that the TCT extension is not needed in AAL1 CES and that the AAL1
CES microcode uses this Hword to point to a CAS routing table.
0x5C UEAD_OFFSET Hword User-defined cells mode only. The offset of the UEAD entry in the UDC
extra header. Should be an even address. If RCT[BO]=01
UEAD_OFFSET should be in little-endian format. For example if UEAD
entry is the first half word of the extra header in external memory,
UEAD_OFFSET should be set to 2 (second half word entry in internal
RAM).
0x5E — Hword Reserved, should be cleared during initialization.
0x60 PMT_BASE Hword Performance monitoring table base. User-defined.
0x62 APCP_BASE Hword APC parameters table base address. User-defined.
0x64 FBT_BASE Hword Free buffer pool parameters table base. User-defined.
0x66 INTT_BASE Hword Interrupt queue parameters table base. User-defined.
0x5E — — Reserved, should be cleared during initialization.
0x6A UNI_STATT_BASE Hword UNI statistics table base. User-defined.
0x6C BD_BASE_EXT Word BD table base address extension. BD_BASE_EXT[0–7] holds the 8 left
bits of the Rx/Tx BD table base address. BD_BASE_EXT[8–31] should
be zero. User-defined.
0x70 VPT_BASE /
EXT_CAM_BASE Word Base address of the address compression VP table/external CAM.
User-defined.
0x74 VCT_BASE Word Base address of the address compression VC table. User-defined.
0x78 VPT1_BASE /
EXT_CAM1_BASE Word Base address of the address compression VP1 table/EXT CAM1.
User-defined.
0x7C VCT1_BASE Word Base address of the address compression VC1 table. User-defined.
0x80 VP_MASK Hword VP mask for address compression lookup. User-defined.
Table 31-3. AAL1 CES Field Descriptions (continued)
Offset Name Width Description
