MPC8260 PowerQUICC II Family Reference Manual, Rev. 2
Freescale Semiconductor A-1
Appendix A
Register Quick Reference Guide
A0
This section provides a brief guide to the core registers.
A.1 PowerPC Registers—User Registers
The implements the user-level registers defined by the PowerPC architecture except those required for
supporting floating-point operations (the floating-point register file (FPRs) and the floating-point status
and control register (FPSCR)). User-level PowerPC registers are listed in
Table A-1 and Table A-2 .
Table A-2 lists user-level special-purpose registers (SPRs).
Table A-2 lists SPRs defined by the PowerPC architecture implemented on the MPC8260.
A.2 PowerPC Registers—Supervisor Registers
All supervisor-level registers implemented on the MPC8260 are SPRs, except for the machine state
register (MSR), described in
Table A-3 .
Table A-1. User-Level PowerPC Registers (non-SPRs)
Description Name Comments Access Level Serialize Access
General-purpose
registers GPRs The thirty-two 32-bit (GPRs) are used for source
and destination operands. User —
Condition register CR See the Programming Environments Manual User Only mtcrf
Table A-2. User-Level PowerPC SPRs
SPR Number
Name Comments Serialize Access
Decimal SPR [5–9] SPR [0–4]
1 00000 00001 XER See the Programming
Environments Manual
Write: Full sync
Read: Sync relative to load/store operations
8 00000 01000 LR See the Programming
Environments Manual
No
9 00000 01001 CTR See the Programming
Environments Manual
No
268 01000 01100 TBL read
1
1 Extended opcode for mftb, 371 rather than 339.
See the Programming
Environments Manual
Write (as a store)
269 01000 01101 TBU read
2
2
Any write (mtspr) to this address causes an implementation-dependent software emulation exception.
