This filter causes rasterization in 3D groups.
Original image Displace applied with a jellyfish as map image
Parameters in the Inspector
Map Image: An image well that displays a thumbnail of the map chosen.
Horizontal Scale: Sets the horizontal scaling of the object.
Vertical Scale: Sets the vertical scaling of the object.
Repeat Edges: Sets whether or not the edges of the object are repeated.
Mix: Sets what percentage of the original image is blended with the distorted image.
HUD Controls
The HUD contains the following controls: Map Image, Horizontal Scale, Vertical Scale, and
Repeat Edges.
Droplet
This filter simulates the effect of a drop of liquid falling onto the surface of a pool, with
your image displaced as the surface of the pool. This filter is not automatically animated,
but animating the Thickness parameter of this filter creates the effect of the ripples
spreading out from the center.
This filter causes rasterization in 3D groups.
Original image Droplet applied
