Brocade Network Advisor SAN + IP User Manual 901
53-1002949-01
Steps for connecting to a KMIP-compliant SafeNet KeySecure
25
Importing the TKLM certificate into the group leader
The TKLM certificate must be imported from the location on the host to the encryption Group
Leader node. The encryption Group Leader exports the certificate to group member switches.
1. Select Configure > Encryption from the menu task bar to display the Encryption Center
dialog box. (Refer to Figure 303 on page 852.)
2. Select a switch from the Encryption Center Devices table, then select Switch > Import
Certificate from the menu task bar.
The Import Signed Certificate dialog box displays. (Refer to Figure 323 .)
FIGURE 323 Import Signed Certificate dialog box
3. Browse to the location where the signed certificate is stored, then click OK.
The signed certificate is stored on the switch.
Steps for connecting to a KMIP-compliant SafeNet KeySecure
With the introduction of Fabric OS 7.1.0, the Key Management Interoperability Protocol (KMIP)
KeySecure Management Console can be used on the switch. Any KMIP-compliant server can be
reregistered as a KMIP key vault on the switch after setting the key vault type to KMIP.
Currently, KMIP with SafeNet KeySecure 6.1 in native KMIP mode with the Brocade Encryption
Switch in KMIP mode is supported. All nodes in an encryption group should be running Fabric OS
7.1.0 and later for the key vault type to be set to KMIP.
After installing the SafeNet KeySecure appliance (also referred to as the KeySecure), you must
complete the following steps before the switch can be configured with the KeySecure. These steps
must be performed only once, in preparation for first-time configuration.
NOTE
If you are configuring two KeySecure nodes, you must complete step 1 through step 6 on the primary
node, then complete step 7 on the secondary node. If only a single node is being configured, step 7
is not needed.
The following suggested order of steps must be completed to create a secure connection to the
SafeNet KeySecure.
1. Set FIPS compliance. (Refer to “Setting FIPS compliance” on page 902.)
2. Create a local CA. (Refer to “Creating a local CA” on page 903.)
3. Create a server certificate. (Refer to “Creating a server certificate” on page 904.)
4. Create a cluster. (Refer to “Creating a cluster” on page 909.)
5. Create a Brocade group on the KeySecure appliance. (Refer to “Configuring a Brocade group
on the KeySecure” on page 910.)
