1328 Brocade Network Advisor SAN + IP User Manual
53-1002949-01
LSP
37
Viewing saved LSP configurations
Take the following steps to view all saved LSP configurations.
1. Select Configure > MPLS > LSP.
2. Select the Saved Configurations tab ( Figure 569 ).
FIGURE 569 LSP dialog box, Saved Configurations tab
Saved LSP configurations are listed by name, description, payload, and deployment schedule.
Adding an LSP admin group
MPLS interfaces can be organized into administrative groups (admin groups). Typically, an admin
group is used to identify a network segment. You can use admin groups to manage CSPF path
selection by including or excluding network segments identified as admin groups. If you include an
admin group, only those segments in that admin group are selected. If you exclude an admin group,
that admin group is excluded from CSPF path selection.
Metrics can be associated with individual admin groups and applied on the particular segments. If
you do not use include and exclude to manage admin groups, paths are selected based on the
metrics associated with the individual admin groups.
This dialog box is the first page of the Admin Group Configuration Wizard. It allows you to provide a
name and ID for the Admin Group and to assign the ports used as interfaces.
1. Select Configure > MPLS > LSP.
2. Select the Admin Groups tab.
