Monitoring Flows

TABLE 149

Flows panel information (Monitor feature selected)

Column

Information Displayed

Sub Flow ID

Sub-flow database ID.

Target Switch

Name of the target switch for the flow.

Flow Name

Name of flow as defined.

Source

SIDs as defined or learned.

Source Info

This field is either empty or displays the inferred destination device (either a VM,
host or storage) based on the source ID. The name of the VM, host, or storage
displays with a hyper link to the device’s property sheet.

Destination

DIDs as defined or learned.

Destination Info

SCSI Read Frame Count
(frames)

SCSI read command count as reported in the last data point for the flow.

SCSI Write Frame Count
(frames)

SCSI write command count as reported in the last data point for the flow.

SCSI Read Data Rate
(Mbps)

SCSI read frame rate as reported in the last data point for the flow.

SCSI Write Data Rate
(Mbps)

SCSI write frame rate as reported in the last data point for the flow.

SCSI Read Data (bytes)

SCSI read data as reported in the last data point for the flow.

SCSI Write Data (bytes)

SCSI write data as reported in the last data point for the flow.

SCSI Read Frame Rate (f/s)

SCSI read frame rate in frames per second as reported in the last data point for the
flow.

SCSI Write Frame Rate (f/s)

SCSI write frame rate in frames per second as reported in the last data point for the
flow.

Transmit Frame Count
(frames)

Transmit frame count as reported in the last data point for the flow.

Receive Frame Count
(frames)

Receive frame count as reported in the last data point for the flow.

Transmit Frame Rate (f/s)

Transmit frame rate as reported in the last data point for the flow.

Receive Frame Rate (f/s)

Receive frame rate as reported in the last data point for the flow.

Transmit Word Count
(bytes)

Transmit word count as reported in the last data point for the flow.

Receive Word Count (bytes)

Receive word count as reported in the last data point for the flow.

Transmit Throughput
(Mbps)

Transmit throughput as reported in the last data point for the flow.

Receive Throughput (Mbps)

Receive throughput as reported in the last data point for the flow.

Ingress Port

Source port as defined for the flow.

Egress Port

Destination port as defined for the flow.

LUN

LUN values as defined for the flow.

Bi-Direction

Yes or No as defined for the flow.
