SAN device properties
E
3. Click OK on the Properties dialog box to close.
iSCSI Node Type The node type of the product.
iSCSI Service The service status; for example, running or not running.
iSNS IP Address The IP address of the server to which the product is pointed.
ISNS IP Address A list of the iSNS IP addresses this product has been assigned by the user
to query.
iSNS Service Whether the product is registered with an iSNS server.
Location The location of the product.
Management Link The management link status (Up/Down) of the product.
Name (Product) The name of the product.
OS The name of the operating system running on the product.
OS Build The operating system build running on the product.
OS Release The operating system release running on the product.
Portal Addresses The list of IP addresses.
Port The port number.
Protocol Error Count The number of protocol errors.
Tag The group tag ID of the portal.
Sessions button Select to display the Filer Sessions dialog box for the product.
Statistics button Select to display the Filer iSCSI Statistics dialog box for the product.
Storage Arrays The number of arrays containing LUNs masked to the server.
Storage Logins The number of unique filers to which hosts on this server are logged in.
Target Portals table Target portals of the product.
Total LUN Size (GB) The size in gigabytes (GB) of all unique LUNs (not LUN paths) masked to
the product.
Vendor The vendor of the product.
Field Description
