IP device properties
E
Memo Additional comments regarding the switch.
Vendor The switch vendor.
Model The switch model type (VDX 6710, VDX 6720, or VDX 6730).
Port Count The number of ports on the switch.
Firmware The firmware version and build number.
Location The physical location of the product.
Contact The name of the person or group you should contact about the product,
for example, Technical Support.
Description The description of the product.
Connected AP Count The number of AP devices connected to the device.
Add button Click to add a user-defined property. For more information, refer to
“Adding a property field” on page 1991.
Edit button Click to edit a user-defined property. For more information, refer to
“Editing a property field” on page 1991.
Delete button Click to delete a user-defined property. For more information, refer to
“Deleting a property field” on page 1992.
Port Profiles tab Select to display information about port profiles on the fabric.
Name The name of the port profile (not editable). There are multiple default
profiles in a fabric (one per member).
Status Port profile states can be one of the following, all of which are configured
using the command line interface:
•
Created
•
Activated
•
Associated
•
Applied
MAC Count The number of MAC addresses associated with the port profile.
VLANs The number of virtual LANs (VLANs) associated with the port profile,
along with the following VLAN information:
•
All — Indicates that the port profile will allow all VLAN IDs.
•
None — Indicates that the port profile will not allow any VLAN IDs.
•
All Except <VLAN IDs> — Indicates that the port profile will allow any
packet except the VLAN IDs specified.
•
<VLAN IDs> — Indicates that the port profile will allow any packet
with the VLAN IDs specified.
QoS Indicates whether the QoS profile is associated with the port profile and,
if there is an associated QoS profile, whether it is in DCB or non-DCB
mode.
ACL Displays the type of access control list (ACL) profile (Standard or
Extended), if an ACL is associated with the port profile.
Field/Component Description
