1868 Brocade Network Advisor SAN + IP User Manual
53-1002949-01
IP Layer 3 VLAN report
52
You can sort the report by clicking on a column header. For example, if you want to sort the table by
tag mode, click the Tag Mode column header.
IP Layer 3 VLAN report
The Layer 3 VLAN report contains links to lists of protocol VLANs associated with a port VLAN. To
view the list of protocol VLANs, click a link under the Layer 3 VLANs section of the Port VLANs
report. The Layer 3 VLAN report displays.
If the report is empty, then there are no protocol VLANs that have been configured for the port
VLAN. The Layer 3 VLAN report has the parameters described in
Table 190 .
If any protocol or subnet VLANs have been configured under the protocol VLAN, you can click the
Details link for that VLAN to find out more information for that VLAN.
IP Subnet report
The IP Subnet report displays the list of IP subnets discovered on the network. To appear on this
list, the subnet must contain at least one discovered product.
To view the IP Subnet report, select Reports > IP Subnet Reports. The IP Subnet report has the
parameters described in
Table 191 .
Port VLAN Information This section contains the Layer 3 VLANs list, which displays links to protocol VLANs
associated with the port VLAN.
Ports in Port VLAN #: This section shows the following information:
•
Product — The name of the products that have ports belonging to the VLAN.
For VCS fabric members, displays the VCS IP address with the name of the
products that have ports belonging to the VLAN.
•
Interface — The port number or slot number that belongs to the VLAN.
•
Interface Name — The name of the interface.
•
Tag Mode — Whether the port is tagged, untagged, dual, or blank.
•
PVLAN Type — The PVLAN type.
TABLE 189 Port VLANs report fields and components (Continued)
TABLE 190 Layer 3 VLAN report fields and components
Field/Component Description
Protocol VLANs in Port VLAN This section lists the details of protocol VLANs configured under the port VLAN.
IP Subnet VLANs in Port
VLAN # Several sections on the report display the subnet VLANs that have been configured
under the port VLAN.
TABLE 191 IP Subnet report fields and components
Field/Component Description
IP Address The list of IP subnets discovered on the network. These address are listed in
numerical order.
Subnet Mask The mask of the subnet.
Products A link to a list of products in the subnet.
