Monitoring Flows

Information displayed when Mirror enabled

Table 151

describes information on sub-flows displayed in the Flows panel when you select Mirror

from the Feature list above the Flows panel.

NOTE

For Flow Mirror, statistic counts greater than zero imply that the mirrored flow is functioning, but
should not be inferred as accurate counts at this time.

TABLE 151

Flows panel information (Mirror feature selected)

Column

Information Displayed

Sub Flow Id

Sub-flow database ID.

Target Switch

Name of the target switch for the flow.

Flow Name

Name of flow as defined.

Source

SIDs as defined or learned.

Source Info

This field is either empty or displays the inferred destination device (either a VM,
host or storage) based on the source ID. The name of the VM, host, or storage
displays with a hyper link to the device’s property sheet.

Destination

DIDs as defined or learned.

Destination Info

Mirrored Frames Count
(frames)

Mirrored frames count as reported in the last data point received for the flow

Mirrored Transmit Frames
(frames)

The number of transmitted mirrored frame as reported in the last data point
received for the flow.

Mirrored Receive Frames
(frames)

The number of received mirrored frame as reported in the last data point received
for the flow

Ingress Port

Ingress port as defined for the flow

Egress Port

Egress port as defined for the flow.

LUN

LUN values as defined for the flow.

Bi-Direction

Yes or No as defined for the flow.

Flow Definition Persistence

Either Yes if “Persist over switch reboots” is defined in the flow or No.

Frame Type

Frame types as defined for the flow.

Size

Size of the frame payload.

Pattern

Pattern of the frame payload.

Last Updated Time

The time when the sub-flows were last updated.
