6 RLC Swept SA Measurement Front-Panel & SCPI Reference
Quick Save
Quick Save
The Quick Save front-panel key repeats the most recent save that was performed from the Save
menu, with the following exceptions:
l
Register saves are not remembered as Saves for the purpose of the Quick Save function
l
If the current measurement does not support the last non-register save that was performed, an
informational message is generated, “File type not supported for this measurement”
Quick Save repeats the last type of qualified save (that is, a save qualified by the above criteria)
in the last save directory by creating a unique filename using the Auto File Naming algorithm
described below.
If Quick Save is pressed after startup and before any qualified Save has been performed, the
Quick Save function performs a Screen Image save using the current settings for Screen Image
saves (current theme, current directory), which then becomes the “last save” for the purpose of
subsequent Quick Saves.
The Auto File Naming feature automatically generates a file name for use when saving a file. The
filename consists of a prefix and suffix separated by a dot, as is standard for the Windows® file
system. A default prefix exists for each of the available file types:
Type
Default Prefix
Menu
State
State_
(Save/Recall)
Trace + State
State_
(Save/Recall)
Screen
Screen_
(Save/Recall)
Amplitude Corrections
Ampcor_
(Import/Export)
Traces
Trace_
(Import/Export)
Limit Lines
LLine_
(Import/Export)
Measurement Result
MeasR_
(Import/Export)
Capture Buffer
CapBuf_
(Import/Export)
A four digit number is appended to the prefix to create a unique file name. The numbering
sequence starts at 0000 within each Mode for each file type and updates incrementally to 9999,
then wraps to 0000 again. It remembers where it was through a Mode Preset and when leaving
and returning to the Mode. It is reset by Restore Misc Defaults and Restore System Defaults and
subsequent running of the instrument application. So, for example, the first auto file name
generated for State files is State_0000.state. The next is State_0001, and so forth.
