6 RLC Swept SA Measurement Front-Panel & SCPI Reference
Input/Output
State Saved Saved in instrument state.
Min –100 dB
Max 100 dB
Readback MS, dB
Initial S/W Revision Prior to A.02.00
Remote Command [:SENSe]:CORRection:MS[:RF]:LOSS
[:SENSe]:CORRection:MS[:RF]:LOSS?
Example CORR:MS:LOSS 10 sets the Ext Gain value to –10 dB, and subsequently querying :LOSS will give
10 dB
CORR:MS:LOSS –10 sets the Ext Gain value to 10 dB, and subsequently querying :LOSS will give
–10 dB
Notes A positive value of in the above command means a loss and a negative value
indicates a gain.
Anytime :LOSS is set it sets :GAIN to the negative value of the parameter sent.
Anytime :LOSS is queried it gives the negative of :GAIN
Preset This is unaffected by a Preset but is set to 0 dB on a "Restore Input/Output Defaults" or
"Restore System Defaults->All"
Min 100 dB
Max –100 dB
Initial S/W Revision Prior to A.02.00
BTS
Sets an external attenuation value for BTS (Base Transceiver Station) tests.
Key Path Input/Output, External Gain
Remote Command [:SENSe]:CORRection:BTS[:RF]:GAIN
[:SENSe]:CORRection:BTS[:RF]:GAIN?
Example CORR:BTS:GAIN 10 sets the Ext Gain value to 10 dB
CORR:BTS:GAIN –10 sets the Ext Gain value to –10 dB (that is, a loss of 10 dB.)
Notes Does not auto return.
Dependencies The reference level limits are determined in part by the External Gain, Max Mixer Level, RF Atten
Remote Language Compatibility Measurement Application Reference 621
