6 RLC Swept SA Measurement Front-Panel & SCPI Reference
Input/Output
Antenna Unit
For devices (like antennas) that make measurements of field strength or flux density, the
correction array should contain within its values the appropriate conversion factors such that,
when the data on the analyzer is presented in dBµV, the display is calibrated in the appropriate
units. The "Antenna Unit" used for the conversion is contained within the corrections array
database. It may be specifiedor loaded in from an external file or SCPI.
When an array with an Antenna Unit other than "None" is turned on, the Y Axis Unit of the
analyzer is forced to that unit. When this array is turned on, and it contains an Antenna Unit
other than “None”, the Y Axis Unit of the analyzer is forced to that Antenna Unit., and all other Y
Axis Unit choices are grayed out.
Antenna Unit does not appear in all Modes that support Corrections. Only the modes listed in
the Mode row of the table below support Antenna Units.
Key Path
Input/Output, Corrections, Properties
Mode
SA
Remote Command
[:SENSe]:CORRection:CSET[1]:ANTenna[:UNIT] GAUSs | PTESla | UVM | UAM |
UA | NOConversion
[:SENSe]:CORRection:CSET[1]:ANTenna[:UNIT]?
Example
CORR:CSET:ANT GAUS
Dependencies
Only the first correction array (Correction 1) supports antenna units.
Note that this means that a correction file with an Antenna Unit can only be loaded into the
Corrections 1 register. Consequently only for Correction 1 does the dropdown in the Recall dialog
include.ant, and if an attempt is made to load a correction file into any other Correction register
which DOES contain an antenna unit, a Mass Storage error is generated.
Preset
Unaffected by Preset. Set to NOC by Restore Input/Output Defaults
State Saved
Saved in instrument state
Initial S/W Revision
A.02.00
None
Selects no antenna unit for this Correction set. Thus no Y Axis unit will be forced.
Key Path
Input/Output, Corrections, Properties, Antenna Unit
Example
:CORR:CSET:ANT NOC
Readback
"None"
Initial S/W Revision
A.02.00
