6 RLC Swept SA Measurement Front-Panel & SCPI Reference
Save
Save As…
When you press “Save As”, the analyzer brings up a Windows dialog and a menu entitled “Save
As.” This menu allows you to navigate to the various fields in the Windows dialog without using
a keyboard or mouse. The Tab and Arrow keys can also be used for dialog navigation.
See "To File . . ." on page 1020 in Save, State for a full description of this dialog and menu.
The default path for Screen Images is
My Documents\\screen.
where is the parameter used to select the mode with the INST:SEL command (for
example, SA for the Spectrum Analyzer).
Key Path Save, Screen Image
Notes Brings up Save As dialog for saving a Screen Image Save Type
Initial S/W Revision Prior to A.02.00
Mass Storage Catalog (Remote Command Only)
Remote Command :MMEMory:CATalog? []
Notes The string must be a valid logical path.
Queries disk usage information (drive capacity, free space available) and obtains a list of files and
directories in a specified directory in the following format:
,,{}
It returns two numeric parameters and as many strings as there are files and directories. The
first parameter indicates the total amount of storage currently used in bytes. The second
parameter indicates the total amount of storage available, also in bytes. The is a
string. Each indicates the name, type, and size of one file in the directory list:
,,
As the windows file system has an extension that indicates file type, is always
empty. provides the size of the file in bytes. For directories, is
surrounded by square brackets and both and are empty
Initial S/W Revision Prior to A.02.00
Mass Storage Change Directory (Remote Command Only)
Remote Command :MMEMory:CDIRectory []
:MMEMory:CDIRectory?
Remote Language Compatibility Measurement Application Reference 1119
