6 RLC Swept SA Measurement Front-Panel & SCPI Reference
Sweep/Control
Preset Off
GSM/EDGE: RFBurst
State Saved Saved in instrument state
Readback The current setting is read back to this key and it is also Readback to the previous Periodic Timer
trigger key.
Backwards
Compatibility SCPI :TRIGger[:SEQuence]:FRAMe:SYNC EXTernal
For backward compatibility, the parameter EXTernal is mapped to EXTernal1
Initial S/W Revision Prior to A.02.00
Modified at S/W
Revision A.03.00
Off
Turns off the sync source for your periodic trigger. With the sync source off, the timing will drift
unless the signal source frequency is locked to the analyzer frequency reference.
Key Path Trigger, Periodic Timer, Sync Source
Example TRIG:FRAM:SYNC OFF
Readback Off
Initial S/W Revision Prior to A.02.00
External 1
Pressing this key, when it is not selected, selects an external input signal as the trigger. A new
sweep/measurement will start when the external trigger condition is met using the external 1
input connector on the rear panel.
Pressing this key, when it is already selected, accesses the external 1 trigger setup menu.
Key Path Trigger
Example TRIG:SOUR EXT1 Swept SA measurement
TRIG::SOUR EXT1 Measurements other than Swept SA
Dependencies Grayed out if in use by Point Trigger in the Source Setup menu.
Forced to Free Run if already selected and Point Trigger is set to External 1.
State Saved Saved in instrument state
Status Bits/OPC
dependencies
Remote Language Compatibility Measurement Application Reference 1219
