6 RLC Swept SA Measurement Front-Panel & SCPI Reference
Meas Setup
If the domain of the selected limit does not match the domain of the X Axis, no action is taken.
Standard clipping rules apply, if the value in the table is outside the allowable range for the X
axis.
Key Path Meas Setup, Limits, Edit
Dependencies If either the first or last point in the array is outside the frequency range of the current input, an
error message is generated:
“–221. Settings conflict; Start or Stop Freq out of range for current input settings”
Initial S/W Revision A.02.00
Delete Limit
Deletes the currently selected limit line. Pressing Delete Limit purges the data from the limit line
tables.
Limit data – including secondary parameters such as description, margin value, etc. - will be
cleared and returned to factory preset settings.
When this key is pressed a prompt is placed on the screen that says “Please press Enter or OK
key to delete limit. Press ESC or Cancel to close this dialog.” The deletion is only performed if
you press OK or Enter; if so, after the deletion, the informational message “Limit deleted” appears
in the MSG line.
Key Path Meas Setup, Limits
Remote Command :CALCulate:LLINe[1]|2|...6:DELete
Example :CALC:LLIN2:DEL deletes all data for limit line 2.
Initial S/W Revision A.02.00
Test Limits
Selects whether displayed traces are tested against displayed limits (i.e. those for which Limit
On/Off is set to On).
For each displayed trace for which a Limit is turned on, a message will be displayed in the upper-
left corner of the graticule to notify whether the trace passes or fails the limits.
If the trace is at or within the bounds of all applicable limits and margins, the text “Trace x Pass”
will be displayed in green, where x is the trace number. A separate line is used for each reported
trace.
Remote Language Compatibility Measurement Application Reference 821
