Pinout
MCF548x Reference Manual, Rev. 3
Freescale Semiconductor 31-7
M23 VSS — — — AF9 E0TXCLK PFEC0H7 — —
M24 EVDD — — — AF10 E0MDIO PFECI2C3 — —
M25 PCIAD12 — FBADDR12 — AF11 E0RXD3 PFEC0L3 — —
M26 PCIAD13 — FBADDR13 — AF12 E0RXD2 PFEC0L2 — —
N1 SDCLK0 — — — AF13 E0RXD1 PFEC0L1 — —
N2 SDCLK0 — — — AF14
3
USBCLKOUT — — —
N3 SDCS0 — — — AF15
3
USBCLKIN — — —
N4 SDDATA7 — — — AF16
3
USBD+ — — —
N11 VSS — — — AF17
3
USBD- — — —
N12 VSS — — — AF18 USBRBIAS — — —
N13 VSS — — — AF19 DREQ1 PDMA1 TIN1 IRQ1
N14 VSS — — — AF20 DREQ0 PDMA0 TIN0 —
N15 VSS — — — AF21 TIN2 PTIM5 IRQ2 CANRX1
N16 VSS — — — AF22 TIN0 — — —
N23 PCIAD16 — FBADDR16 — AF23 PSC3CTS PPSC3PSC27 PSC3BCLK —
N24 PCIAD14 — FBADDR14 — AF24 1 E1RXD0 PFEC1H1 — —
N25 PCIAD17 — FBADDR17 — AF25 PSC1CTS PPSC1PSC07 PSC1BCLK —
N26 PCIAD15 — FBADDR15 — AF26 TOUT0 — — —
1
This pin is a “no connect” on the MCF5483 and MCF5482 devices.
2 This pin is a “no connect” on the MCF5481 and MCF5480 devices. On MCF5485, MCF5484, MCF5483, and MCF5482 device
the pin should be connected to the appriopriate power rail even is USB is not being used.
3
This pin is a “no connect” on the MCF5481 and MCF5480 devices.
Table 31-1. MCF5485/MCF5484 Signal Description by Pin Number (Continued)
PBGA
Pin
Pin Functions
PBGA
Pin
Pin Functions
Primary GPIO Secondary Tertiary Primary GPIO Secondary Tertiary
