MCF548x Reference Manual, Rev. 3
29-6 Freescale Semiconductor
0xB164 EP2 OUT interface number register,
EP2 OUT status register EP2OUTIFR EP2OUTSR — —
0xB168 Reserved
0xB16C EP2 OUT Sync Frame Register EP2OUTSFR
0xB170–
0xB177 Reserved
0xB178 EP2 IN attribute control register,
EP2 IN max packet size register — EP2INACR EP2INMPSR
0xB17C EP2 IN interface number register,
EP2 IN status register EP2INIFR EP2INSR — —
0xB180–
0xB184 Reserved
0xB188 EP2 IN sync frame register EP2INSFR
0xB18C–
0xB18F Reserved
0xB190 EP3 OUT attribute control register,
EP3 OUT max packet size register – EP3OUTAC
R
EP3OUTMPSR
0xB194 EP3 OUT interface number register,
EP3 OUT status register EP3OUTIFR EP3OUTSR — —
0xB198 Reserved
0xB19C EP3 OUT sync frame register EP3OUTSFR
0xB1A0–
0xB1A7 Reserved
0xB1A8 EP3 IN attribute control register,
EP3 IN max packet size register – EP3INACR EP3INMPSR
0xB1AC EP3 IN interface number register,
EP3 IN status register EP3INIFR EP3INSR — —
0xB1B0–
0xB1B7 Reserved
0xB1B8 EP3 IN sync frame register EP3INSFR
0xB1BC–
0xB1BF Reserved
0xB1C0 EP4 OUT attribute control register,
EP4 OUT max packet size register — EP4OUTAC
R
EP4OUTMPSR
0xB1C4 EP4 OUT interface number register,
EP4 OUT status register EP4OUTIFR EP4OUTSR — —
0xB1C8 Reserved
0xB1CC EP4 OUT sync frame register EP4OUTSFR
Table 29-1. USB Memory Map (Continued)
Address
(MBAR +)
Name Byte0 Byte1 Byte2 Byte3
