Floating-Point Exceptions
MCF548x Reference Manual, Rev. 3
Freescale Semiconductor
6-17
6.6
Floating-Point Exceptions
This section describes floating-point exceptions and how they are handled.
lists the vector
numbers related to floating-point exceptions. If the exception is taken pre-instruction, the PC contains the
address of the next floating-point instruction (nextFP). If the exception is taken post-instruction, the PC
contains the address of the faulting instruction (fault).
NGLE
Not greater, less or equal
NAN
011000
Yes
IEEE-Aware Tests
EQ
Equal
Z
000001
No
NE
Not equal
Z
001110
No
OGT
Ordered greater than
NAN | Z | N
000010
No
ULE
Unordered or less or equal
NAN | Z | N
001101
No
OGE
Ordered greater than or equal
Z | (NAN | N)
000011
No
ULT
Unordered or less than
NAN | (N & Z)
001100
No
OLT
Ordered less than
N & (NAN | Z)
000100
No
UGE
Unordered or greater or equal
NAN | (Z | N)
001011
No
OLE
Ordered less than or equal
Z | (N & NAN)
000101
No
UGT
Unordered or greater than
NAN | (N | Z)
001010
No
OGL
Ordered greater or less than
NAN | Z
000110
No
UEQ
Unordered or equal
NAN | Z
001001
No
OR
Ordered
NAN
000111
No
UN
Unordered
NAN
001000
No
Miscellaneous Tests
F
False
False
000000
No
T
True
True
001111
No
SF
Signaling false
False
010000
Yes
ST
Signaling true
True
011111
Yes
SEQ
Signaling equal
Z
010001
Yes
SNE
Signaling not equal
Z
011110
Yes
1
This column refers to the value in the instruction’s conditional predicate field that specifies this test.
Table 6-9. Floating-Point Conditional Tests (Continued)
Mnemonic
Definition
Equation
Predicate
1
EXC[BSUN] Set
