10.3
XL Bus Arbiter
The XL bus arbiter handles bus arbitration between XL bus masters.
10.3.1
Features
The arbiter features are as follows:
•
Eight priority levels
•
Priority levels may be changed dynamically by XL bus masters
•
XL bus arbitration support for eight masters
•
Least recently used (LRU) priority scheme for masters of equal priority
•
Multiple masters at each priority level supported
•
One level of address pipelines is enforced by the arbiter
•
Bus grant parking modes:
— No parking
— Park on last master
— Park on programmed master
•
Watchdog timers for various XL bus time-out conditions
10.3.2
Arbiter Functional Description
10.3.2.1
Prioritization
The prioritization function will indicate that a master is requesting the bus and indicate which master has
priority.
Priority is determined first by using the hardcoded master priority or the master n priority bits in the arbiter
master priority register (XARB_PRIEN), depending on the arbiter master priority enable bit for each
master. Secondly, masters at the same level of priority will be further sorted by a least recently used
9
PSCEN
PSC Clock Enable - Controls clock for all PSC modules.
8
—
Reserved, should be cleared.
7
USBEN
USB Clock Enable
6
FEC1EN
FEC1 Clock Enable
5
FEC0EN
FEC0 Clock Enable
4
DMAEN
Multi-channel DMA Clock Enable
3
CAN0EN
CAN0 Clock Enable
2
FBEN
FlexBus Clock Enable
1
PCIEN
PCI Bus Clock Enable
0
MEMEN
Memory Clock Enable - Controls clocks of the SDRAM controller module
Table 10-3. SPCR Field Descriptions (Continued)
Bits
Name Description
