Functional Description
MCF548x Reference Manual, Rev. 3
Freescale Semiconductor
20-5
20.3.2
PCI Arbiter Status Register (PASR)
20.4
Functional Description
20.4.1
External PCI Requests
An external PCI master may target the MCF548x or external slaves. The request/grant handshake always
precedes any PCI bus operation. The PCI arbiter must service access requests for an external
master-to-external target transactions as well as external master-to-MCF548x transactions.
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
R
0
0
0
0
0
0
0
0
0
0
EXTMBK
ITLMBK
W
rwc
1
rwc
1
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
R
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
W
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Reg
Addr
MBAR + 0xC04
1
Bits 21-16 are read-write-clear (rwc).
—Hardware can set rwc bits, but cannot clear them.
—Software can clear rwc bits that are currently set by writing a 1 to the bit location. Writing a 1 to a rwc bit
that is currently a 0 or writing a 0 to any rwc bit has no effect.
Figure 20-3. PCI Arbiter Status Register (PASR)
Table 20-3. PASR Field Descriptions
Bits
Name
Description
31–22
—
Reserved. Software should write zero to this register.
21–17
EXTMBK
External master broken: External master time-out. Bit 17 reports the time-out status for the device
using REQ0 and GNT0 pins, bit 18 for REQ1 and GNT1, etc. A CPU interrupt will be generated if
the corresponding external master interrupt enable bit is set. Software must write a 1 to each bit
location to clear.
16
ITLMBK
Internal master broken: An MCF548xmaster time-out occurred. A CPU interrupt will be generated
if the internal master interrupt enable bit is set. Software must write a 1 to this bit location to clear.
15–0
—
Reserved. Software should write zero to this register.
