15.3.2.2.5
FBCS Register (PDDR_FBCS)
The 5-bit PDDR_FBCS register is for data direction of PFBCSn.
displays the 5-bit
PDDR_FBCS register.
15.3.2.3
Port x Pin Data/Set Data Registers (PPDSDR_x)
The PPDSDR registers reflect the current pin states and control the setting of output pins when the pin is
configured for general purpose I/O.
7
6
5
4
3
2
1
0
R
0
0
0
0
DDx3
DDx2
DDx1
DDx0
W
Reset
0
0
0
0
0
0
0
0
Reg
Addr
MBAR + 0xA12 (PDDR_DMA), 0xA18 (PDDR_FECI2C)
Figure 15-10. 4-Bit PDDR_DMA and PDDR_FECI2C Registers
Table 15-12. 4-Bit PDDR_DMA and PDDR_FECI2C Field Descriptions
Bits
Name Description
7–4
—
Reserved, should be cleared
3–0
DDxn
PDDR_DMA and PDDR_FECI2C Data Direction
0 PDMAn or PFECI2Cn pin is configured as input
1 PDMAn or PFECI2Cn pin is configured as output
7
6
5
4
3
2
1
0
R
0
0
DDFB5
DDFB4
DDFB3
DDFB2
DDFB1
0
W
Reset
0
0
0
0
0
0
0
0
Reg
Addr
MBAR + 0xA11 (PDDR_FBCS)
Figure 15-11. 5-Bit PDDR_FBCS Register
Table 15-13. 5-Bit PDDR_FBCS Field Descriptions
Bits
Name Description
7–6
—
Reserved, should be cleared
5–1
DDFBn
PDDR_FBCS data direction
0 PFBCSn pin is configured as input
1 PFBCSn pin is configured as output
0
—
Reserved, should be cleared
