Page 448: Figure 17-36

MCF548x Reference Manual, Rev. 3
17-32
Freescale Semiconductor
Figure 17-36. Example of a Misaligned Word Transfer (32-Bit Port)
17.6.8
Bus Errors
The MCF548x has no bus monitor. If the auto-acknowledge feature is not enabled for the address that
generates the error, the bus cycle can be terminated by asserting TA or by using the software watchdog
timer. If it is required that the MCF548x handle a bus error differently, an interrupt handler can be invoked
by asserting an interrupt to the core along with TA when the bus error occurs.
––
––
––
Byte 0
Transfer 1
Byte 0
––
––
—
Transfer 2
001
100
16 15
31
0
24 23
7
8
A[2:0]
