26.3.3.11 Counter Timer Registers (PSCCTURn, PSCCTLRn)
These registers hold the upper and lower bytes of the preload value to be used by the PSC timer in order
to provide a given baud rate.
26.3.3.12 Input Port (PSCIPn)
The PSCIP shows the current state of the input ports.
7
6
5
4
3
2
1
0
Mode
R
CT[15:8]
UART /
SIR
W
R
0
0
0
0
0
0
0
0
All other
modes
W
Reset
0
0
0
0
0
0
0
0
Reg
Addr
MBAR + 0x8618 (PSC0); 0x8718 (PSC1); 0x8818 (PSC2); 0x8918 (PSC3)
Figure 26-16. Counter Timer Upper Register (PSCCTURn)
Table 26-15. PSCCTURn Field Descriptions
Bits
Name
Description
7–0
CT [15:8]
PSCCTUR. For UART and SIR modes this field signifies the baud rate prescale value. The
baud rate is calculated as
Baud rate = (system clock frequency) / (CT[15:0]
Ч 16 Ч 2)
The minimum CT value is 1 and 0 denotes the counter stop.
Table 26-16. PSCCTLRn Field Descriptions
Bits
Name
Description
7–0
CT [7:0]
PSCCTLR. For UART and SIR modes this field signifies the baud rate prescale value. The
baud rate is calculated as
Baud rate = (system clock frequency) / (CT[15:0]
Ч 16 Ч 2)
The minimum CT value is 1 and 0 denotes the counter stop.
Table 26-17. PSCIPn Field Descriptions
Bits
Name
Description
7
LPWR_B
In UART, IrDA, and modem modes this bit is reserved.
In AC97 mode, this bit signifies the low power mode:
0 CODEC is in low power mode.
1 Usual operation
6
TGL
In UART and IrDA modes this bit is reserved.
In AC97 and modem modes, this bit signifies test usage.
Toggle by frame sync.
