MCF548x Reference Manual, Rev. 3
15-10
Freescale Semiconductor
15.3.2.1.3
5-Bit PODR_x Registers
The 5-bit PODR_x registers are the output data registers for PPCIBGn (PODR_PCIBG) and PPCIBRn
(PODR_PCIBR).
displays the 5-bit PODR_x registers.
15.3.2.1.4
4-Bit PODR_x Registers
The 4-bit PODR_x registers are the output data registers for PDMAn (PODR_DMA) and PFECI2Cn
(PODR_FECI2C).
displays the 4-bit PODR_x registers.
7
6
5
4
3
2
1
0
R
0
PODRDSPI6 PODRDSPI5 PODRDSPI4 PODRDSPI3 PODRDSPI2 PODRDSPI1 PODRDSPI0
W
Reset
0
1
1
1
1
1
1
1
Reg
Addr
MBAR + 0xA0E (PODR_DSPI)
Figure 15-3. 7-Bit PODR_DSPI Register (PODR_x)
Table 15-5. 7-Bit PODR_DSPI Field Descriptions
Bits
Name Description
7
—
Reserved, should be cleared
6–0
PODRDSPIn
PODR DSPI output data bits
0 Drive 0 when PDSPIn pin is general purpose output
1 Drive 1 when PDSPIn pin is general purpose output
7
6
5
4
3
2
1
0
R
0
0
0
PODRx4
PODRx3
PODRx2
PODRx1
PODRx0
W
Reset
0
0
0
1
1
1
1
1
Reg
Addr
MBAR + 0xA09 (PODR_PCIBG), 0xA0A (PODR_PCIBR)
Figure 15-4. 5-Bit PODR_PCIBG and PODR_PCIBR Registers
Table 15-6. 5-Bit PODR_PCIBG and PODR_PCIBR Field Descriptions
Bits
Name Description
7–5
—
Reserved, should be cleared
4–0
PODRxn
PODR_PCIBG and PODR_PCIBR output data bits
0 Drive 0 when PPCIBGn or PPCIBRn pin is general purpose output
1 Drive 1 when PPCIBGn or PPCIBRn pin is general purpose output
