Chapter 12
Slice Timers (SLT)
12.1
Introduction
This chapter explains the operation of the MCF548x slice timers.
12.1.1
Overview
Two slice timers are included to provide shorter term periodic interrupts—SLT0 and SLT1. Each timer
consists of a 32-bit counter with no prescale. The counters count down from a prescribed value and
expire/interrupt when they reach zero. They can be configured to automatically preset to the prescribed
value and resume counting or wait until the status/interrupt is serviced before beginning a new cycle.
The current count value can be read without disturbing the count operation. Each SLT has a status bit to
indicate the timer has expired. If enabled, a CPU interrupt is generated at count expiration. Each timer has
a separate interrupt. Clearing the status and/or interrupt is accomplished by writing 1 to the status bit, or
disabling the timer entirely with the timer enable (SCR[TEN]) bit.
Software should write a terminal count value of greater than 255.
12.2
Memory Map/Register Definition
There are two slice timers. Each one uses four 32-bit registers. These registers are located at an offset from
MBAR of 0x900.
summarizes the SLT control registers.
Table 12-1. Slice Timer Memory Map
Address
(MBAR +)
Name
Byte 0
Byte 1
Byte 2
Byte 3
Access
0x900
SLT Terminal Count Register 0
STCNT0
R/W
0x904
SLT Control Register 0
SCR0
R/W
0x908
SLT Count Value Register 0
SCNT0
R
0x90C
SLT Status Register 0
SSR0
R
0x910
SLT Terminal Count Register 1
STCNT1
R/W
0x914
SLT Control Register 1
SCR1
R/W
0x918
SLT Count Value Register 1
SCNT1
R
0x91C
SLT Status Register 1
SSR1
R
