EU Specific Data Packet Descriptors
MCF548x Reference Manual, Rev. 3
Freescale Semiconductor 22-85
Table 22-78 lists several different descriptors that use the format shown in Table 22-77 .
22.14.5.2 Statically Assigned AESU
Table 22-69 shows the first descriptor for a statically assigned AESU.
PTR_6 IV Out Pointer Address where output IV is to be written (optional)
LEN_7 MAC Out Length NULL
PTR_7 MAC Out Pointer NULL
PTR_NEXT Next Descriptor Pointer Pointer to next data packet descriptor
Table 22-78. Typical Header Values for Dynamic AESU Format
Header Value Mode E/D
0x6030010 CBC Encrypt
0x60200010 CBC Decrypt
0x6010010 ECB Encrypt
0x60000010 ECB Decrypt
0x60600010 CTR —
Table 22-79. First Descriptor for a Statically Assigned AESU
Field Name Value/Type Description
Header see Table 22-80 Header common to several descriptors (TYPE 0001)
LEN_1 Length (not used) NULL
PTR_1 Pointer (not used) NULL
LEN_2 IV Length Number of bytes in input IV (56 bytes) (optional)
PTR_2 IV Pointer Address of input IV (optional)
LEN_3 Key Length Number of bytes in Key (16, 24, or 32 bytes)
PTR_3 Key Pointer Address of Key
LEN_4 Data In Length Number of bytes of data to be ciphered (multiple of 16)
PTR_4 Data In Pointer Address of data to be ciphered
LEN_5 Data Out Length Bytes of output data (should be equal to length of data in)
PTR_5 Data Out Pointer Address to write output data
LEN_6 IV Out Length NULL
PTR_6 IV Out Pointer NULL
LEN_7 MAC Out Length NULL
Table 22-77. Descriptor for a Dynamically Assigned AESU (Continued)
Field Name Value/Type Description
