Instructions
MCF548x Reference Manual, Rev. 3
Freescale Semiconductor
6-29
Some differences affect function activation and return. M68000 subroutines typically began with
FMOVEM #list,-(a7) to save registers on the system stack, with each register occupying three longwords.
In ColdFire, each register occupies two longwords and the stack pointer must be adjusted before the
FMOVEM instruction. A similar sequence generally occurs at the end of the function, preparing to return
control to the calling routine.
The examples in
,
show a M68000 operation and the equivalent
ColdFire sequence.
If the subroutine includes LINK and UNLK instructions, the stack space needed for FPU register storage
can be factored into these operations and LEA instructions are not required.
The M68000 FPU supports loads and stores of multiple control registers (FPCR, FPSR, and FPIAR) with
one instruction. For ColdFire, only one can be moved at a time.
For instructions that require an unsupported addressing mode, the operand address can be formed with a
LEA instruction immediately before the FPU operation. See
The M68000 FPU allows floating-point instructions to directly specify immediate values; the ColdFire
FPU does not support these types of immediate constants. It is recommended that floating-point immediate
Support for fpGEN xxx.{w,l},FPx
Yes
No
Support for fpGEN d
8
(PC,Xi),FPx
Yes
No
Support for fpGEN #xxx,FPx
Yes
No
Support for fmovem (Ay)+,#list
Yes
No
Support for fmovem #list,-(Ax)
Yes
No
Support for fmovem FP Control Registers
Yes
No
Table 6-27. M68000/ColdFire Operation Sequence 1
1
1
n is the number of FP registers to be saved/restored.
M68000
ColdFire Equivalent
fmovem.x #list,-(a7)
lea -8*n(a7),a7;allocate stack space
fmovem.d #list,(a7) ;save FPU registers
fmovem.x (a7)+,#list
fmovem.d (a7),#list ;restore FPU registers
lea 8*n(a7),a7 ;deallocate stack space
Table 6-28. M68000/ColdFire Operation Sequence 2
M68000
ColdFire Equivalent
fadd.s label,fp2
lea label,a0;form pointer to data
fadd.s (a0),fp2
fmul.d (d8,a1,d7),fp5
lea (d8,a1,d7),a0;form pointer to data
fmul.d (a0),fp5
fcmp.l (d8,pc,d2),fp3
lea (d8,pc,d2),a0;form pointer to data
fcmp.l (a0),fp3
Table 6-26. Key Programming Model Differences (Continued)
Feature
M68000
ColdFire
