SDRAM Example
MCF548x Reference Manual, Rev. 3
Freescale Semiconductor
18-25
18.8.1
SDRAM Signal Drive Strength Settings
The SDRAMDS should be programmed as shown in
. The settings assume the normal drive
strength for 2.5V drive, 7.6mA, is sufficient for the loading in the system.
This configuration results in a value of SDRAMDS = 0x0000_02AA, as described in
18.8.2
SDRAM Chip Select Settings
For this example, the SDRAM will be connected to SDCS0 with a base address of 0x0. All other chip
selects are unused and do not need to be initialized. The CS0CFG should be programmed as shown in
.
Write recovery timer (t
WR
)
15 ns
Precharge command to
ACTV
command (t
RP
)
15 ns (min) 18ns (max)
Auto refresh command period (t
RFC
)
72ns (min) 75ns (max)
Average periodic refresh interval (t
REFI
)
7.8
µs
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
Field
—
Setting
0000_0000_0000_0000
(hex)
0
0
0
0
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Field
—
SB_E
SB_C
SB_A
SB_S
SB_D
Setting
0000_0010_1010_1010
(hex)
0
2
A
A
Figure 18-14. SDRAM Example Drive Strength Settings (SDRAMDS)
Table 18-15. SDRAMDS Field Descriptions
Bits
Name
Setting
Description
31–10
—
0
Reserved. Should be cleared
9–8
SB_E
10
2.5V, 7.6mA SSTL_2 Class I drive
7–6
SB_C
10
2.5V, 7.6mA SSTL_2 Class I drive
5–4
SB_A
10
2.5V, 7.6mA SSTL_2 Class I drive
3–2
SB_S
10
2.5V, 7.6mA SSTL_2 Class I drive
1–0
SB_D
10
2.5V, 7.6mA SSTL_2 Class I drive
Table 18-14. SDRAM Example Specifications (Continued)
Parameter
Specification
