24.3.3.12 Task Size Registers (TSKSZ[0:1])
Each of the 16 tasks can be programmed to use specific source and destination sizes contained in a task
size register instead of a specific type encoded in a DRD. The ADS module uses the task size register
information to determine the source and destination transfer size of the operands. When the size contained
in the DRD is set to 2’b11 then specific source and destination size fields from the task size register are
selected.
6 none USB device Tx/Rx endpoint 0
7 none USB device Tx/Rx endpoint 1
8 none USB device Tx/Rx endpoint 2
9 none USB device Tx/Rx endpoint 3
10 none PCI Tx
11 none PCI Rx
12 none PSC1 Rx
13 none PSC1 Tx
14 none I
2
C Rx
15 none I
2
C Tx
16 1:0 FEC0 Rx Reserved
17 3:2 FEC0 Tx Reserved
18 5:4 Reserved Reserved FEC0 Rx
19 7:6 Reserved Reserved FEC0 Tx Reserved
20 9:8 Reserved FEC1 Rx Reserved Reserved
21 11:10 DREQ1 FEC1 Tx Reserved Reserved
22 13:12 Reserved FEC0 Rx Reserved Reserved
23 15:14 Reserved FEC0 Tx Reserved Reserved
24 17:16 Reserved CommTimer0 FEC1 Rx Reserved
25 19:18 Reserved CommTimer1 FEC1 Tx Reserved
26 21:20 USB Endpoint 4 Reserved CommTimer2 Reserved
27 23:22 USB Endpoint 5 Reserved CommTimer3 Reserved
28 25:24 USB Endpoint 6 CommTimer4 DREQ1 PSC2 Rx
29 27:26 Reserved DREQ1 CommTimer5 PSC2Tx
30 29:28 FEC1 Rx CommTimer6 Reserved PSC3 Rx
31 31:30 FEC1 Tx Reserved CommTimer7 PSC3 Tx
Figure 24-13. Initiator Assignments (Continued)
Request
Number (of
Source)
Initiator Mux
Control
Register Bit
Encoding
00 01 10 11
