3.6.2 Instruction Set Summary
Table 3-8 lists user-mode instructions by opcode.
Save Internal Floating Point State fsave x Yes
Floating-Point Square Root fsqrt.{b,w,l,s,d} y FPx Yes
Floating-Point Subtract fsub.{b,w,l,s,d} y FPx Yes
Test Floating-Point Operand ftst.{b,w,l,s,d} y Yes
1
Operand sizes in this column reflect only newly supported operand sizes for existing instructions (Bcc, BRA,
BSR, CMP, CMPA, CMPI, and MOVE)
Table 3-8. User-Mode Instruction Set Summary
Instruction Operand Syntax Operand Size Operation
ADD
ADDA
Dy,x
y,Dx
y,Ax L
L
L Source + Destination
→ Destination
ADDI
ADDQ
#,Dx
#,x
L
L Immediate Data + Destination
→ Destination
ADDX Dy,Dx L Source + Destination + CCR[X]
→ Destination
AND y,Dx
Dy,x L
L Source
& Destination → Destination
ANDI #, Dx L Immediate Data
& Destination → Destination
ASL Dy,Dx
#,Dx
L
L CCR[X,C]
← (Dx << Dy) ← 0
CCR[X,C]
← (Dx << #) ← 0
ASR Dy,Dx
#,Dx
L
L msb
→ (Dx >> Dy) → CCR[X,C]
msb
→ (Dx >> #) → CCR[X,C
Bcc B, W, L If Condition True, Then PC + d
n
→ PC
BCHG Dy,x
#,x
B, L
B, L ~ ( of Destination)
→ CCR[Z] →
of Destination
BCLR Dy,x
#,x
B, L
B, L ~ ( of Destination)
→ CCR[Z];
0
→ of Destination
BRA B, W, L PC + d
n
→ PC
BSET Dy,x
#,x
B, L
B, L ~ ( of Destination)
→ CCR[Z];
1
→ of Destination
BSR B, W, L SP – 4
→ SP; nextPC → (SP); PC + d
n
→ PC
BTST Dy,x
#,x
B, L
B, L ~ ( of Destination)
→ CCR[Z]
CLR x B, W, L 0
→ Destination
Table 3-7. V4 New Instruction Summary (Continued)
Instruction Mnemonic
1
Source Destination M68000
