MCF548x Reference Manual, Rev. 3
15-16
Freescale Semiconductor
15.3.2.3.3
5-Bit PPDSDR_x Registers
The 5-bit PPDSDR_x registers are the pin data and set data registers for PPCIBGn (PPDSDR_PCIBG) and
PPCIBRn (PPDSDR_PCIBR).
displays the 5-bit PPDSDR_x registers.
7
6
5
4
3
2
1
0
R
0
PPDx6
PPDx5
PPDx4
PPDx3
PPDx2
PPDx1
PPDx0
W
PSDx6
PSDx5
PSDx4
PSDx3
PSDx2
PSDx1
PSDx0
Reset
0
P
1
P
1
P
1
P
1
P
1
P
1
P
1
Reg
Addr
MBAR + 0xA2E (PPDSDR_DSPI)
1
P = the current pin state.
Figure 15-13. 7-Bit Port Pin Data / Set Data Registers
Table 15-15. 7-Bit PPDSDR_DSPI Field Descriptions
Bits
Name Description
7
—
Reserved, should be cleared.
6–0
PPDxn
PPDSDR_DSPI pin data. This is Read-only.
0 PDSPIn pin state is low
1 PDSPIn pin state is high
PSDxn
PPDSDR_DSPI set data.
0 No effect
1 Corresponding PODR_DSPI bit is set
7
6
5
4
3
2
1
0
R
0
0
0
PPDx4
PPDx3
PPDx2
PPDx1
PPDx0
W
PSDx4
PSDx3
PSDx2
PSDx1
PSDx0
Reset
0
0
0
P
1
P
1
P
1
P
1
P
1
Reg
Addr
MBAR + 0xA29 (PPDSDR_PCIBG) and 0xA2A (PPDSDR_PCIBR)
1
P = the current pin state.
Figure 15-14. 5-Bit PPDSDR_PCIBG and PPDSDR_PCIBR Registers
Table 15-16. 5-Bit PPDSDR_PCIBG and PPDSDR_PCIBR Field Descriptions
Bits
Name Description
7–5
—
Reserved, should be cleared.
