ARC Four Execution Unit (AFEU)
MCF548x Reference Manual, Rev. 3
Freescale Semiconductor
22-31
22.8.4
AFEU Interrupt Status Register (AFISR)
The interrupt status register, seen in
, tracks the state of possible errors, if those errors are not
masked via the AFEU interrupt mask register.
Figure 22-23. AFEU Interrupt Status Register (AFISR)
describes AFEU interrupt status register fields.
25
ID
Interrupt done. This status bit reflects the state of the DONE interrupt signal, as sampled by the
controller interrupt status register (
Section 22.6.4.4, “SEC Interrupt Status Registers (SISRH and
0 AFEU is not signaling done
1 AFEU is signaling done
24
RD
Reset done. This status bit, when set, indicates that AFEU has completed its reset sequence, as
reflected in the signal sampled by the appropriate crypto-channel.
0 Reset in progress
1 Reset done
23–0
—
Reserved, should be cleared.
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
R
ME
AE
OFE
IFE
0
IFO
OFU
0
0
0
0
IE
ERE
CE
KSE
DSE
W
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
R
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
W
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Reg
Addr
MBAR + 0x28030
Table 22-20. AFISR Field Descriptions
Bits
Names
Description
31
ME
Mode error. An illegal value was detected in the mode register. Note: writing to reserved bits in mode
register is likely source of error.
0 No error detected
1 Mode error
30
AE
Address error. An illegal read or write address was detected within the AFEU address space.
0 No error detected
1 Address error
Table 22-19. AFSR Field Descriptions (Continued)
Bits
Name
Description
