EU Specific Data Packet Descriptors
MCF548x Reference Manual, Rev. 3
Freescale Semiconductor
22-77
22.14.3 MDEU Mode Options and Data Packet Descriptors
The MDEU mode options, shown in
, contains 8 bits which are used to program the MDEU.
The mode options are cleared when the MDEU is reset or re-initialized. Setting a reserved mode bit will
generate a data error. If the mode options are modified during processing, a context error will be generated.
describes MDEU mode option fields.
0x20600010
CBC
Triple DES
Decrypt
0x20100010
ECB
Single DES
Encrypt
0x20000010
ECB
Single DES
Decrypt
0x20300010
ECB
Triple DES
Encrypt
0x20200010
ECB
Triple DES
Decrypt
7
6
5
4
3
2
1
0
Field
CONT
—
INT
HMAC
PD
ALG
Reset
0000_0000
Loc
PMODE/SMODE Field in DPD Header
Figure 22-48. MDEU Mode Options
Table 22-65. MDEU Mode Option Field Descriptions
Bits
Name
Description
7
CONT
Continue. Used during HMAC/HASH processing when the data to be hashed is spread
across multiple descriptors.
0 Don’t Continue- operate the MDEU in auto completion mode.
1 Preserve context to operate the MDEU in continuation mode.
6–5
—
Reserved
4
INT
Initialization. Cause an algorithm-specific initialization of the digest registers. Most
operations will require this bit to be set. Only static operations that are continuing from a
known intermediate hash value would not initialize the registers.
0 Do not initialize
1 Initialize the selected algorithm’s starting registers
3
HMAC
HMAC enable. Identifies the hash operation to execute:
0 Perform standard hash
1 Perform HMAC operation. This requires a key and key length information.
Table 22-64. Typical Header Values Final Static DEU Descriptor Format (Continued)
Header Value
E/C
S/T
E/D
