13 debug comparator registers (dbgcompn), 14 debug control (dbgctl), Debug comparator registers (dbgcompn) -16 – Freescale Semiconductor MCF5480 User Manual
Page 736: Debug control (dbgctl) -16

MCF548x Reference Manual, Rev. 3
24-16
Freescale Semiconductor
24.3.3.13 Debug Comparator Registers (DBGCOMPn)
24.3.3.14 Debug Control (DBGCTL)
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
R
Comparator Value
W
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
R
Comparator Value
W
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Reg
Addr
MBAR + 0x8070
Figure 24-16. Debug Comparator Register (DBGCMPn)
Table 24-12. Debug Comparator Field Descriptions
Bits
Name Description
31–0
Comparator
Value
Comparator value for comparator 1 or comparator 2.
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
R
Block Tasks[15:0]
W
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
R
AA
B
Comparator 1 Type Comparator 2 Type AND/
OR
0
0
0
0
E
I
0
W
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Reg
Addr
MBAR + 0x8078
Figure 24-17. Debug Control Register (DBGCTL)
