MCF548x Reference Manual, Rev. 3
14-6 Freescale Semiconductor
Table 14-7. EPFR Field Descriptions
Bits Name Description
7–1 EPFn Edge port flag bits. When an EPORT pin is configured for edge triggering, its corresponding
read/write bit in EPFR indicates that the selected edge has been detected. Reset clears
EPF7–EPF1.
Bits in this register are set when the selected edge is detected on the corresponding pin. A bit
remains set until cleared by writing a 1 to it. Writing 0 has no effect. If a pin is configured as
level-sensitive (EPPARn = 00), pin transitions do not affect this register.
0 Selected edge for IRQx pin has not been detected.
1 Selected edge for IRQx pin has been detected.
0 — Reserved, should be cleared.
